Savx Solar Inverter F3 3500-24V( MPPT BASE)

3500VA / 3500W Solar Inverter

Key Features:

• Rated Power: 3500VA / 3500W

• Output Type: Pure Sine Wave (stable & clean electricity for sensitive electronics)

• Battery Support: 24VDC (compatible with lithium & lead-acid batteries)

• Solar Charger: Built-in 100A MPPT (fast and efficient charging)

• Dual Charging: Solar & AC

• Efficiency: Up to 93%

• Display: Smart LCD for real-time monitoring

• Communication Interface: USB / RS232 (Optional: CAN & RS485)

• Safety Compliance: EN/IEC62109-1 & EN/IEC62109-2

• Surge Power: 7000VA

Technical Specifications:

AC Input:

• Voltage: 230VAC (Selectable 220–240V)

• Voltage Range:

  • 170–280VAC (For PC)

  • 90–280VAC (For Home Appliances)

• Frequency: 50Hz / 60Hz (Auto sensing)

AC Output:

• Voltage Regulation: 230VAC ±5%

• Transfer Time: 10ms (PC), 20ms (Home Appliances)

• Waveform: Pure Sine Wave

Battery System:

• Battery Voltage: 24VDC

Solar & AC Charging:

• Max PV Open Circuit Voltage: 500VDC

• Max PV Array Power: 4500W

• MPPT Range: 60–450VDC

• Max Solar Charge Current: 100A

• Max AC Charge Current: 80A

• Max Combined Charge Current: 100A

General:

• Operating Temperature: -10°C to 50°C

• Humidity: 5%–95% RH (non-condensing)

• Dimensions: 400×300×115 mm

• Net Weight: 8.2kg

Display & Communication:

• Display: Smart LCD

• Communication: USB / RS232 (Standard), CAN & RS485 (Optional)

Warranty:

• 2 Years Parts Warranty

• 5 Years Service Warranty

Applications:

• Perfect for off-grid homes and hybrid solar systems
