Growatt SPE 12000 ES Solar Inverter for Hybrid (Official )

📦 GROWATT SPE 12000 ES (Official) –  📦

🟩 🔌 Input Data (DC):
▸ Max. PV Power: 15000W
▸ Max. DC Voltage: 550V
▸ Start Voltage: 120V
▸ MPP Voltage Range: 60V – 480V
▸ No. of MPPT Trackers: 2
▸ No. of PV Strings per MPPT: 1
▸ Max. Input Current per MPPT: 27A

🟩 ⚡ Output Data (AC):
▸ AC Nominal Power: 12000W
▸ Max. Apparent Power: 12000VA
▸ Nominal AC Voltage: 230V
▸ AC Grid Frequency: 50/60Hz
▸ Output Current: 52.2A
▸ Adjustable Power Factor: 0.8 lagging ~ 0.8 leading
▸ THD: < 5%
▸ Max. Conversion Efficiency: 96.5%
▸ European Efficiency: 95.5%

🟩 🔋 Battery Data (DC):
▸ Nominal DC Voltage: 48V
▸ Max. Charging/Discharging Current: 250A / 280A
▸ Battery Type: Lithium / Lead-acid

🟩 🔌 Backup Power (AC):
▸ Nominal Output Power: 12000W
▸ Output Voltage: 230V
▸ Frequency: 50/60Hz
▸ Switch Time: <20ms (Single), <30ms (Parallel)

🟩 📈 Efficiency:
▸ Peak Efficiency: 96.5%
▸ European Efficiency: 95.5%

🟩 📐 General Information:
▸ Dimensions (W × H × D): 550×465×150 mm
▸ Weight: 21.5 kg
▸ Operating Temp Range: –10°C to +50°C
▸ Noise Emission: <75 dB
▸ Self Consumption: <75W
▸ Topology: Transformerless
▸ Cooling: DC Fan
▸ Protection Degree: IP20
▸ Relative Humidity: 5%–95% (non-condensing)
▸ Altitude: <2000m
▸ Communication: WiFi / GPRS
▸ Certification: CE, NRS097
